Metal Shell Waterproof Access Control Keypad Reader with Wiegand 26-37 Interface for 125KHz EM Card

Metal Shell Waterproof Access Control Keypad Reader with Wiegand 26-37 Interface for 125KHz EM Card

Features:

• Card Type: 125 KHz EM card. Wiegand Interface: Wiegand 26-37 bit.
• The “#” key can be used as doorbell button.
• IP65 waterproof keypad and proximity card reader in one device.
• Designed for outdoor environments with a sealed, weatherproof design allowing you to easily mount anywhere.
• Protects from unwanted entry with rugged vandal-resistant backlit metal enclosure.
• Very Low Power Consumption (<35mA), long service life and stable performance
• Application in High-Security Places: Warehouses,,commercial building, banks, villa, prisons, etc
• Backlight keypad
• With manager cards for adding or deleting card user easily
• Wiegand 26-37 bit input & output,can be programmed
• Protective Properties: IP65 fully-potted
• This series of products are using the new 32-bit microcontroller ARM core design with powerful functions. They are very stable and reliable. It’s a new generation of multi-function access controller, include Reader mode, Single-door mode, Double-doors mode, Interlock mode, Demo mode etc. All of them could be widely used in office buildings, homes, schools, condominium, apartments, flats, single houses, banks, prisons and other places.

Specifications:

• Operating Voltage: AC/DC10-28V
• User capacity: 20000
• Card Type: 125KHz EM
• PIN length: 4-8 digits
• Wiegand Interface: Wiegand 26-37 bit
• Working mode can be set: Controller mode, reader mode, interlock mode and demo mode
• Specific reader mode: Customer can set output format
• Access mode: Card/PIN/Card+PIN
• User capacity: 20000
• Support programming card, enter programming mode fast
• Self-adaption infrared detection
• Adjustable Door Relay Time: 1-99s
• Standby Current: <35mA (Input DC12V)
• Operating current: ≤100mA (Input DC12V)
• Card Read Rang: <5cm
• Operating Temperature: -40℉~140℉
• Operating Humidity: 0-95%
• Lock Output Load: 1A
• Alarm Output Load: 3A
• Antistatic: 15KV
• Environment: Conforms to IP65
• Wiring Length: 35.73-39.37in
• Dimensions: L5.04xW3.22xH1.1(in)

Package:

• 1 x Digital Keypad
• 1 x User Manual
• 1 x Screw Driver
• 4 x Rubber Bungs
• 4 x Self Tapping Screws
• 1 x Diode
